Parameters
1. Power supply: DC12-13.8V Recommend 12V
2. Maximum operating current: 1A
3. Ambient temperature: -5~40℃
4. Frequency Range: 76MHz~108MHz
5. Frequency Step : 100KHz
6. Frequency Stabilize Style: PLL
7. Pre-emphasize : Default 50µs Optional 75µs
8. Output power: from 0.1 to 1.2W Power adjustable
9. Output resistance: 50 OHM
10. Modulate Style: WFM
11. Maximum Deviation: ±75KHz
12. Parasitic AM: 〈0.2%
13. Audio Frequency Response: 50Hz~15000Hz
14. Audio input level: -15dbV（Max: -30dbV）
15. Input Jack: 3.5mm headphone connector and RCA jack
16. MIC input Level: -15dbV（Max: -45dbV）
17. MIC Jack： 3.5mm headphone connector
18. Stereo Seperation： Better than 30db
19. S/N： Better than 50db
20. Antenna Connector： SMA type
21. Dimension： 98x140x50mm
22. Weight： 0.7Kg
ATTENTION Never power on the transmitter when the antenna is not connected!!!
Package Content :
TX-01S FM Transmitter
Power supply
Portable Antenna
Audio cable
