Parameters
1. Power supply: DC12-13.8V Recommend 12.8V
2. Maximum operating current: 4A
3. Ambient temperature: -5~40℃
4. Frequency Range: 87MHz~108MHz
5. Frequency Step : 100KHz
6. Frequency Stabilize Style: PLL
7. Pre-emphasize : Default 50µs Optional 75µs
8. Output power: 0 to 1000mW±10%
9. Output resistance: 50 OHM
10. Modulate Style: WFM
11. Maximum Deviation: ±75KHz
12. Parasitic AM: 〈0.2%
13. Audio Frequency Response: 50Hz~15000Hz
14. Audio input level: -15dbV（Max: -30dbV）
15. Input Jack: 3.5mm headphone connector and RCA jack
16. MIC input Level: -15dbV（Max: -45dbV）
17. MIC Jack： 3.5mm headphone connector
18. Stereo Seperation： Better than 30db
19. S/N： Better than 50db
20. Antenna Connector： N type
21. Dimension： 250x160x54CM
22. Weight： 1.6Kg
